USB Type-C PD Power Adapter Solution
Different Language Version: [Traditional Chinese] | [Simplified Chinese]
USB Type-C PD Power Adapter Solution
USB Power Delivery (USB PD) is a power supply technology defined by the USB Implementers Forum (USB IF). Historically, the maximum power delivery of the USB port was defined as 2.5W for USB 2.0 and 4.5W for USB 3.0. However, these power levels are too low to support the fast charging requirements of large-capacity batteries. Subsequently, the USB PD specification was raised to 65W and then to 100W, utilizing a new, Type-C connector. The Type-C connector, which does not have orientation challenges of older USB types, can also support a higher current, and hence higher charging speed, than the traditional USB connectors.
Recently, the USB IF announced the USB PD charging specification version 3.1, which increased the USB PD power level from 100W to a maximum of 240W. This large step forward in power delivery makes USB PD applicable in more devices and the list of supported devices was greatly expanded, adding more high-performance devices such as gaming laptops.
EDOM Technology has put together a family of complete solutions for fast charging needs. These solutions are based on internationally certified semiconductors and protective mechanisms for batteries to ensure customer designs can be executed offering both performance and safety.
EDOM’s USB Type-C interface PD Power Adapter solution comprises components including MPS controllers, Sinopower power components, Canyon and Injoinic USB PD solutions chips, and a variety of other high-performance chips.
EDOM offers a broad spectrum of product lines to enable our customers to customize their products to their specific market needs.
Solution Block Diagram
Related Product
Canyon USB PD Charger - CY2332 / CY6572
Canyon USB PD Charger targeted for USB-Type-C adapter and charger application. It has passed USB-IF certifications of USB power delivery specification Rev 3.0 V1.2 with PPS. Also, it is compatible with Qualcomm QC4/4+ protocol. [Learn More]
Injoinic Synchronous-Rectified Buck Converter - IP6505
IP6505 is a Synchronous-Rectified Buck Converter and support 10 fast charge output standards, providing solutions for car charger, fast charge adaptor and smart power strip. [Learn More]
Sinopower N-Channel Enhancement Mode MOSFET- SM6125NSKP
SM6125NSKP can be used in Load Switching、Motor Control and DC/DC Converter. When this MOSFET is activated as ON, this condition results in the maximum amount of the current flow through the device. [Learn More]
MPS Synchronous Rectifier - MP6925A
MP6925A is a fast turn-off, CCM/DCM compatible Dual-LLC synchronous rectifier with improved noise immunity, and enhanced driver for fast switching. [Learn More]
MPS CC/CV Controller - MP26085
MP26085 is a voltage and current control IC integrated with a precision voltage reference and a current source, which is suitable for battery charger, second controller of switching regulator systems, and other types of application required an accurate voltage and current control systems. [Learn More]
High-Performance Digital PFC + LLC Controller - HR1203
HR1203 is a high-performance controller that integrates an advanced, digital, PFC controller and a half-bridge, LLC resonant controller. The HR1203 requires low input power at no-load or ultra-light load, making it compliant with the Energy Using Product Directive (EuP) Lot 6 and Code of Conduct Version 5 Tier 2 specifications. [Learn More]
